Light Efficient Design’s Post Top LED retrofits have been designed specifically for use in decorative post top and area fixtures. Our omni-directional design delivers unsurpassed lumen output, broad even light distribution, easy installation and up to 80% in energy and labor savings over existing HID technology. All models utilize our Advanced Active Cooling technology delivering consistently higher LED efficacy and life when placed within enclosed fixtures.

Post Top Retrofit Lamps

  • Generation 3 design includes updated driver with integrated surge protection and Advanced Active Cooling delivering unsurpassed performance within enclosed outdoor fixtures.
  • Available in 35W, 45W, 65W and 100W LED models replacing HID Lamps up to 400W.
  • Choice of 3000K, 4000K, or 5700K
  • Safety rated and heat tested within fully enclosed fixtures from -40 to +122F ambient temperatures.
  • UL Listed 1993 and UL Classified 1598C (retrofitted fixture retains UL, E39 models only) within USA and Canada.
  • Includes 6ka internal surge protection

Post Top Retrofit Lamp | Light Efficient Design

Filter
Item Number CA 94577 Canada LUMENS MA 01949 NC 28208 PA 19030 POWER USED ProductSpecRule REPLACES TX 75061 VOLTAGE BASE CCT Unit Purchase
65W FROSTED POST TOP
LED-8046M40-F-A
 58 8 0 100 B 0
Call to order
45W FROSTED POST TOP
LED-8024E40-F-A
 143 9 0 64 B 0
Call to order
POST TOP 45W MOGUL BASE 5700K
COUNTRY:
USA/CAN
CRI:
84.5
DIMENSION _OL x W:
9.75" X 3.3"
DIMMABLE:
No
DUV:
-0.0014
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
11.9
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9598
R9:
15.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
13.9 Lbs
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 12 in.
THD:
11.97
UCC-14:
10 8440060 8053 9
UNIT CTN WEIGHT:
1.45 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 11.5 in.
UPC-12:
8440060 8053 2
WARRANTY:
5 Year Limited
WEIGHT:
1.23 Lbs
LED-8024M57-A
 868 25 6632 65 2151 45W B Up to 250W HID 2753 120-277V E39 Mogul 5700K
Call to order
POST TOP 35W MOGUL BASE 5700K
LED-8033M57-A
 547 -23 37 175 B 421
Call to order
WHILE SUPPLIES LAST
LED-8146M40-A
 326 10 0 181 B 0
Call to order
POST TOP 35W MOGUL BASE 4000K
LED-8033M40C-A
 0 144 0 0 C 0
Call to order
WHILE SUPPIES LAST
LED-8144M30-A
 5 29 0 25 B 0
Call to order
POST TOP 35W MOGUL BASE 3000K
LED-8033M30-A
 0 -193 0 -3 B 0
Call to order
POST TOP 35W MOGUL BASE 4000K
LED-8033M40-A
 661 307 72 729 B 807
Call to order
WHILE SUPPLIES LAST
LED-8144M40-A
 73 1 20 192 B 0
Call to order
WHILE SUPPLIES LAST
LED-8146M30-A
 176 29 1 70 B 0
Call to order
POST TOP 35W MOGUL BASE 3000K
LED-8033M30C-A
 0 143 0 0 C 0
Call to order
WHILE SUPPLIES LAST
LED-8146M50-A
 270 23 126 B 0
Call to order
WHILE SUPPLIES LAST
LED-8145M40-A
 379 5 19 154 B 0
Call to order
POST TOP 35W MOGUL BASE 5700K
LED-8033M57C-A
 0 -24 0 0 C 0
Call to order
POST TOP 35W EDISON BASE 3000K
COUNTRY:
USA/CAN
CRI:
82.3
DIMENSION _OL x W:
8.3" X 3.3 in.
DIMMABLE:
No
DUV:
-0.0015
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
10.0
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9791
R9:
12.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
12 Lbs.
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 11 in.
THD:
13.68
UCC-14:
10 8440060 8110 9
UNIT CTN WEIGHT:
1.24 Lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 10.4 in.
UPC-12:
8440060 8110 2
WARRANTY:
5 Year Limited
WEIGHT:
1.02 Lbs
LED-8033E30-A
 125 42 4239 9 334 35W B Up to 175W HID 0 120-277V E26 Edison 3000K
Call to order
POST TOP 35W EDISON BASE 4000K
COUNTRY:
USA/CAN
CRI:
83.7
DIMENSION _OL x W:
8.3" X 3.3 in.
DIMMABLE:
No
DUV:
0.0009
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
10.0
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.973
R9:
16.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
12 Lbs.
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 11 in.
THD:
16.17
UCC-14:
10 8440060 8110 9
UNIT CTN WEIGHT:
1.24 Lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 10.4 in.
UPC-12:
8440060 8110 2
WARRANTY:
5 Year Limited
WEIGHT:
1.02 Lbs
LED-8033E40-A
 313 12 5468 9 1 35W B Up to 175W HID 887 120-277V E26 Edison 4000K
Call to order
POST TOP 35W EDISON BASE 5700K
COUNTRY:
USA/CAN
CRI:
84.8
DIMENSION _OL x W:
8.3" X 3.3 in.
DIMMABLE:
No
DUV:
0.0023
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
10.0
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9673
R9:
21.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
12 Lbs.
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 11 in.
THD:
16.64
UCC-14:
10 8440060 8111 9
UNIT CTN WEIGHT:
1.24 Lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 10.4 in.
UPC-12:
8440060 8111 9
WARRANTY:
5 Year Limited
WEIGHT:
1.02 Lbs
LED-8033E57-A
 0 60 5617 44 196 35W B Up to 175W HID 558 120-277V E26 Edison 5700K
Call to order
POST TOP 45W EDISON BASE 3000K
COUNTRY:
USA/CAN
CRI:
85.4
DIMENSION _OL x W:
9.6" X 3.3"
DIMMABLE:
No
DUV:
-0.0024
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
11.9
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9364
R9:
21.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
13.7 Lbs
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 12 in.
THD:
19.79
UCC-14:
10 8440060 8034 8
UNIT CTN WEIGHT:
1.45 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 11.5 in.
UPC-12:
8440060 8034 1
WARRANTY:
5 Year Limited
WEIGHT:
1.23 Lbs
LED-8024E30-A
 43 459 6062 16 262 45W B Up to 250W HID 0 120-277V E26 Edison 3000K
Call to order
POST TOP 45W EDISON BASE 4000K
COUNTRY:
USA/CAN
CRI:
85.1
DIMENSION _OL x W:
9.6" X 3.3"
DIMMABLE:
No
DUV:
-0.0015
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
11.9
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.963
R9:
21.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
13.7 Lbs
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 12 in.
THD:
10.06
UCC-14:
10 8440060 8067 6
UNIT CTN WEIGHT:
1.45 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 11.5 in.
UPC-12:
8440060 8067 9
WARRANTY:
5 Year Limited
WEIGHT:
1.23 Lbs
LED-8024E40-A
 345 68 6924 34 546 45W B Up to 250W HID 493 120-277V E26 Edison 4000K
Call to order
POST TOP 45W EDISON BASE 5700K
COUNTRY:
USA/CAN
CRI:
84.0
DIMENSION _OL x W:
9.6" X 3.3"
DIMMABLE:
No
DUV:
0.0016
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
11.9
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9898
R9:
19.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
13.7 Lbs
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 12 in.
THD:
10.49
UCC-14:
10 8440060 8024 9
UNIT CTN WEIGHT:
1.45 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 11.5 in.
UPC-12:
8440060 8024 2
WARRANTY:
5 Year Limited
WEIGHT:
1.23 Lbs
LED-8024E57-A
 1 50 6619 50 151 45W B Up to 250W HID 3 120-277V E26 Edison 5700K
Call to order
POST TOP 45W MOGUL BASE 3000K
COUNTRY:
USA/CAN
CRI:
84.1
DIMENSION _OL x W:
9.75" X 3.3"
DIMMABLE:
No
DUV:
0.003
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
11.9
MIN FIXTURE SIZE-W:
7.4
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9903
R9:
16.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
13.9 Lbs
SHIPPER CTN_DIMS_(LxWxH):
15.6 X 15.6 X 12 in.
THD:
13.1
UCC-14:
10 8440060 8054 6
UNIT CTN WEIGHT:
1.45 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
4.9 X 4.9 X 11.5 in.
UPC-12:
8440060 8054 9
WARRANTY:
5 Year Limited
WEIGHT:
1.23 Lbs
LED-8024M30-A
 0 50 5893 0 44 45W B Up to 250W HID 307 120-277V E39 Mogul 3000K
Call to order
POST TOP 45W MOGUL BASE 4000K
LED-8024M40-A
 1041 18 40 972 B 2293
Call to order
POST TOP 65W MOGUL BASE 3000K
COUNTRY:
USA/CAN
CRI:
84.7
DIMENSION _OL x W:
11.1 X 4.1 in.
DIMMABLE:
No
DUV:
-0.0043
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
13.3
MIN FIXTURE SIZE-W:
8.0
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9862
R9:
20.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
14.8 Lbs
SHIPPER CTN_DIMS_(LxWxH):
17.7 X 11.8 X 13.8 in.
THD:
13.04
UCC-14:
10 8440060 8175 8
UNIT CTN WEIGHT:
2.23 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
5.6 X 5.6 X 13.2 in.
UPC-12:
8440060 8175 1
WARRANTY:
5 Year Limited
WEIGHT:
1.8 Lbs
LED-8046M30-A
 72 28 8450 0 32 65W B Up to 320W HID 0 120-277V E39 Mogul 3000K
Call to order
POST TOP 65W MOGUL BASE 4000K
COUNTRY:
USA/CAN
CRI:
84.1
DIMENSION _OL x W:
11.1 X 4.1 in.
DIMMABLE:
No
DUV:
0.0026
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
13.3
MIN FIXTURE SIZE-W:
8.0
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9823
R9:
12.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
14.8 Lbs
SHIPPER CTN_DIMS_(LxWxH):
17.7 X 11.8 X 13.8 in.
THD:
14.84
UCC-14:
10 8440060 8177 5
UNIT CTN WEIGHT:
2.23 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
5.6 X 5.6 X 13.2 in.
UPC-12:
8440060 8177 8
WARRANTY:
5 Year Limited
WEIGHT:
1.8 Lbs
LED-8046M40-A
 117 73 9587 0 21 517 65W B Up to 320W HID 309 120-277V E39 Mogul 4000K
Call to order
POST TOP 65W MOGUL BASE 5700K
COUNTRY:
USA/CAN
CRI:
85.1
DIMENSION _OL x W:
11.1 X 4.1 in.
DIMMABLE:
No
DUV:
-0.0011
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
13.3
MIN FIXTURE SIZE-W:
8.0
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9872
R9:
16.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
14.8 Lbs
SHIPPER CTN_DIMS_(LxWxH):
17.7 X 11.8 X 13.8 in.
THD:
16.56
UCC-14:
10 8440060 8177 2
UNIT CTN WEIGHT:
2.23 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
5.6 X 5.6 X 13.2 in.
UPC-12:
8440060 8177 5
WARRANTY:
5 Year Limited
WEIGHT:
1.8 Lbs
LED-8046M57-A
 24 27 9499 2 447 65W B Up to 320W HID 543 120-277V E39 Mogul 5700K
Call to order
POST TOP 100W MOGUL BASE 3000K
COUNTRY:
USA/CAN
CRI:
85.5
DIMENSION _OL x W:
11.8 X 4.5 in.
DIMMABLE:
No
DUV:
-0.0028
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
14.0
MIN FIXTURE SIZE-W:
8.5
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9979
R9:
21.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
17.006 Lbs
SHIPPER CTN_DIMS_(LxWxH):
12.9 X 12.9 X 14.8 in.
THD:
8.06
UCC-14:
10 8440060 8037 9
UNIT CTN WEIGHT:
2.9 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
6.1 X 6.1 X 14 in.
UPC-12:
8440060 8037 2
WARRANTY:
5 Year Limited
WEIGHT:
2.86 Lbs
LED-8027M30-A
 46 7 12486 0 61 100W B Up to 400W HID 0 120-277V E39 Mogul 3000K
Call to order
POST TOP 100W MOGUL BASE 4000K
COUNTRY:
USA/CAN
CRI:
85.6
DIMENSION _OL x W:
11.8 X 4.5 in.
DIMMABLE:
No
DUV:
0.0002
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
14.0
MIN FIXTURE SIZE-W:
8.5
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9976
R9:
23.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
17.006 Lbs
SHIPPER CTN_DIMS_(LxWxH):
12.9 X 12.9 X 14.8 in.
THD:
14.76
UCC-14:
10 8440060 8017 1
UNIT CTN WEIGHT:
2.9 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
6.1 X 6.1 X 14 in.
UPC-12:
8440060 8017 4
WARRANTY:
5 Year Limited
WEIGHT:
2.86 Lbs
LED-8027M40-A
 406 172 14666 35 1009 100W B Up to 400W HID 617 120-277V E39 Mogul 4000K
Call to order
POST TOP 100W MOGUL BASE 5700K
COUNTRY:
USA/CAN
CRI:
83.4
DIMENSION _OL x W:
11.8 X 4.5 in.
DIMMABLE:
No
DUV:
0.0038
LIGHT DISTRIBUTION:
Omni-directional /360°
MIN FIXTURE SIZE-H:
14.0
MIN FIXTURE SIZE-W:
8.5
OPERATING TEMPERATURE:
-40°F to +122°F
PF:
0.9978
R9:
13.0
RATED LED LIFE:
50,000 Hrs.
SAFETY CERT:
cULus
SHIPPER CTN WEIGHT:
17.006 Lbs
SHIPPER CTN_DIMS_(LxWxH):
12.9 X 12.9 X 14.8 in.
THD:
14.48
UCC-14:
10 8440060 8027 0
UNIT CTN WEIGHT:
2.9 lbs.
UNIT CTN_DIMENSIONS _LxWxH:
6.1 X 6.1 X 14 in.
UPC-12:
8440060 8027 3
WARRANTY:
5 Year Limited
WEIGHT:
2.86 Lbs
LED-8027M57-A
 789 112 14613 1 1185 100W B Up to 400W HID 478 120-277V E39 Mogul 5700K
Call to order

Light Efficient Design Headquarters · 188 S. Northwest Highway · Cary, IL 60013 · (847) 380-3540 · FAX: (978)-913-3317 · e-mail:sales@led-llc.com
Innovation and Manufacturing Center · 30 Log Bridge Road, Building 200 · Middleton, MA 01949
Specifications are subject to change without notice.

SIGN UP FOR OUR NEWSLETTER
